Alloy Steel T5 Tubes Manufacturer

View Product Details
Alloy Steel T5 Tubes

ASTM A213 T5 Tubes, CrMo T5 Round Tube, Alloy Steel T5 Boiler Tubes, Chrome Moly T5 ERW Tubes, AS T5 Tubing Manufacturers in India, UNS K41545 AS Tubing Exporters, Alloy Steel T5 Seamless Tubes Distributors, Alloy Steel A213 T5 Tube Supplier in Mumbai, India.

Alloy Steel T5 Superheater Tubing, ASTM A213 T5 Alloy Steel Seamless Tube Traders in Mumbai, IBR Alloy Steel T5 Tubes, Alloy Steel T5 Welded Tube, Chromium-Molybdenum Steel 1.7362 Tubing in Mumbai, Alloy Steel T5 High Pressure Tube, Chrome Moly Steel T5 Heat-Exchanger Tubes Stockists in India.

Metinox Overseas manufactures and markets alloy steel T5 tubes that are meant to possess certain mechanical and metallurgical characteristics through the incorporation of a number of alloying elements. Even small amounts of other elements such as nickel and copper have been proved to enhance the resistance of corrosion in even Alloy steel T5 seamless tubes, and molybdenum enhances the resistance of corrosion. The components of the alloying elements in the Alloy Steel T5 welded tubes may either be pure mixtures or compounds and carbides, according to the interactions between them, iron and carbon. Nickel is also very soluble in ferrite and prefers to form compounds which are based on Ni₃Al, but the aluminium is soluble in ferrite and aids in the formation of the compound. Alloy steel T5 manganese tubes are mainly dissolved in ferrite, although they may form (Fe, Mn) carbides. The quantity of carbon and other elements of the alloy will define the nature of chromium carbide in AS T5 tubes.

Nickel, aluminium, and silicon are said to form stable compounds in the AS T5 seamless tubes and strengthen and render them thermally stable. The steelmaking requires the dissolved oxygen, sulphur and phosphorus to be taken out of the molten metal in the AS T5 welded tubes with either manganese, silicon or aluminium to increase the purity and performance of the material. The AS T5 ERW tubes have been reported to provide safe and reliable service in the challenging applications. These types of tubes are very much mechanical at high temperatures up to 930°F (500°C) and at ambient temperatures and are readily produced using conventional industrial procedures. The Alloy steel T5 tubes are also affordable in terms of cost, which is also cost-effective in the event that high temperature and pressure are utilised.

Request a QuoteQuote Icon

Chrome Moly T5 Tubes | EN 10217 Welded Alloy Steel T5 Tubes | Alloy Steel T5B Tubes | Alloy Steel T5C Tubes Manufacturer in Mumbai | Alloy Steel K41545 Tubes Manufacturers in India | Chrome Moly K41545 Seamless Tubes Exporter in India | Ferritic Alloy Steel A213 T5 Seamless Tube | Grade T5 IBR Alloy Steel Tubes | EN 10216 Alloy Steel T5 Seamless Tubing Supplier | EN 10216-2 1.7362 Alloy Steel Tube | EN 10217-2 X11CrMo5 Alloy Steel Tubes for Pressure Purposes at High Temperatures | 5Cr--Mo Alloy Steel Tubes

ASTM A213 Alloy Steel T5 Tube Specification

Parameter Details
Specifications ASTM A213 / ASME SA213
Dimensions ASTM, ASME
Standard EN 10216-2: Seamless steel tubes for pressure purposes. Technical delivery conditions. Non-alloy and alloy steel tubes with specified elevated temperature properties
EN 10217-2: Welded steel tubes for pressure purposes. Electric welded non-alloy and alloy steel tubes with specified elevated temperature properties
Size Range 1/8" ID up to 5" OD, customs diameters also available
Thickness Range SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules, upto 12mm thk
Type Seamless, Welded, ERW
Form Round Tubes, Square Tubes, Rectangular Tubes
Length Single Random, Double Random & Cut Length.
Outside Coating Black Painting, Anti-Corrosion Oil, Galvanised Finish, Finish as per customer Requirements

T5 Alloy Steel Tube Equivalent Standards

Grade UNS Steel Number Trade Name
T5 K41545 1.7362 5Cr-1/2Mo

Alloy Steel ASTM A213 T5 Tube Chemical Composition

Grade T5 C, % Mn, % P, % S, % Si, % Cr, % Mo, %
UNS K41545 0.15 max 0.30-0.60 0.025 0.025 max 0.50 max 4.00-6.00 0.45-0.65

Alloy Steel T5 Tubing Mechanical Properties

Tensile Strength, MPa Yield Strength, MPa Elongation, %
415 min 205 min 30 min

Other types of Alloy Steel T5 Tubes

Chrome Moly A213 T5 Tube, Alloy Steel Tube Price List, Chromium-Molybdenum Steel T5 Seamless Tubing, Alloy Steel T5 Tube price list in India, Alloy Steel T5 Tube Manufacturer in India, Chrome Moly T5 Tubing, ASTM A213 Grade T5 Alloy Steel Tubes, A213 Steel Grade T5 Tube, Alloy Steel T5 Welded Tubing, High Pressure Alloy Steel T5 Seamless Tube, Ferritic Alloy-Steel T5 Tube Supplier in Mumbai, ASTM A213 Alloy Steel T5 Tube exporter in India, ASTM A213 CrMo T5 Seamless Tube, Ferritic Alloy Steel UNS K41545 Boiler Tube, Seamless Alloy Steel T5 Tube, Alloy Steel T5 ERW Tubing
