Metinox Overseas is a leading manufacturer and supplier of Stainless Steel 310H Tubes. The 310h tubes are good in the suppression of atmospheres like sulphuric acids and chloride. This grade is made of austenitic material structure that provides this grade with excellent toughness. The tubes themselves can be processed and even welded in the normal practice of fabricating the shop. The most common type of steel used in industries is the tubes due to their high value and corrosion. In addition, the tubes can perform well in fresh water service coupled with low chlorides. The tubes are also heated in the temperature of 1652 degree Celsius and thereafter they are required by the hot working processes.
Approximately 16 to 24 percent chromium, 35 percent nickel and the minute amount of manganese and carbon are contained in the Stainless steel 310h tube. Other than it, the machining productions of stainless steel tubes are acquired with higher feeds, slow velocity, and even hard tooling and also with superior lubrication. In addition, the tubes are annealed at 1038 degree Celsius also, on account of as much as corrosion resistance. Then the tubes are subjected to different conditions like water tempering, quenching among others. The thickness of the tube ranges between 0.35 and 6.35 and its size ranges between 1/8 NB and 30" NB. Its termination is rounded, beveled and plain. It is half or twice cut length and random length. This tube is available at Metinox Overseas with special testing like non-destructive testing, destructive testing as well as ultrasonic testing.
| Specifications | ASTM A213, A249, A269 / ASME SA213, SA249, SA269 |
| Outside Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24" NB available Ex-stock, OD Size Steel Tubes available Ex-stock |
| Thickness Range | 0.3mm � 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Type | Seamless / ERW / Welded / Fabricated / CDW |
| Form | Round Tubes, Square Tubes, Rectangular Tubes, Coiled Tubes, "U" Shape, Pan Cake Coils, Hydraulic Tubes |
| Length | Single Random, Double Random & Required Length |
| End | Plain End, Beveled End, Treaded |
| Outside Finish | 2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Tubes, Finish as per customer Requirements |
| Delivery Condition | Annealed and Pickled, Polished, Bright Annealed, Cold Drawn |
| EN 10216-5 | EN 10216 Seamless Steel Tubes, EN 10216-5 Seamless Steel Tube for pressure purposes |
| EN 10217-7 | EN 10217 Welded Steel Tubes, Steel EN 10217-7 Welded Tube for pressure purposes |
| STANDARD | UNS | WERKSTOFF NR. | JIS | BS | GOST | EN |
| SS 310H | S31009 | - | - | - | - | - |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 310H | 0.04 � 0.10 | 2.0 max | 1.00 max | 0.045 max | 0.030 max | 24.00 - 26.00 | - | 19.00 - 21.00 | 53.885 min |
| Grade | Tensile Strength | Yield Strength | Elongation | Hardness Rockwell B (HR B) max | Hardness Brinell (HB) max |
| SS 310H | Psi � 75000 , MPa � 515 | Psi � 30000 , MPa � 205 | 40 | 95 | 217 |
| Grade | UNS No | Old British | Euronorm No | Euronorm Name | Swedish SS | Japanese JIS |
| 310H | S31009 | � | X5CrNi18-10 | 2332 | SUS 310H |
| Wall Thickness in mm | 0.5 | 0.6 | 0.7 | 0.8 | 1 | 1.2 | 1.6 | 2 | 2.6 | 3 | 3.2 | 3.6 |
| O. D. in mm Weight in kg/m | ||||||||||||
| 6 | 0.069 | 0.081 | 0.093 | 0.104 | 0.125 | 0.144 | 0.176 | – | – | – | – | – |
| 10 | 0.119 | 0.141 | 0.163 | 0.184 | 0.225 | 0.264 | 0.336 | – | – | – | – | – |
| 12.7 | 0.153 | 0.182 | 0.21 | 0.238 | 0.293 | 0.345 | 0.444 | – | – | – | – | – |
| 14 | 0.169 | 0.201 | 0.233 | 0.264 | 0.325 | 0.384 | 0.496 | – | – | – | – | – |
| 15.87 | 0.192 | 0.229 | 0.266 | 0.301 | 0.372 | 0.44 | 0.571 | 0.694 | – | – | – | – |
| 19 | 0.231 | 0.276 | 0.32 | 0.364 | 0.45 | 0.534 | 0.696 | 0.85 | 1.066 | 1.2 | 1.264 | – |
| 25 | 0.306 | 0.366 | 0.425 | 0.484 | 0.6 | 0.714 | 0.936 | 1.15 | 1.456 | 1.65 | 1.744 | 1.926 |
| 25.4 | 0.311 | 0.372 | 0.432 | 0.492 | 0.61 | 0.726 | 0.952 | 1.17 | 1.482 | 1.68 | 1.776 | 1.962 |
| 31.8 | – | – | – | – | – | 0.918 | 1.208 | 1.49 | 1.898 | 2.16 | 2.288 | 2.538 |
| 38 | – | – | – | – | – | 1.104 | 1.456 | 1.8 | 2.301 | 2.625 | 2.784 | 3.096 |
| 44.5 | – | – | – | – | – | 1.299 | 1.716 | 2.125 | 2.724 | 3.113 | 3.304 | 3.681 |
| 50.8 | – | – | – | – | – | – | 1.968 | 2.44 | 3.133 | 3.585 | 3.808 | 4.248 |
| 63.5 | – | – | – | – | – | – | 2.476 | 3.075 | 3.959 | 4.538 | 4.824 | 5.391 |
| 76.1 | – | – | – | – | – | – | 2.98 | 3.705 | 4.778 | 5.483 | 5.832 | 6.525 |
| 101.6 | – | – | – | – | – | – | 4 | 4.98 | 6.435 | 7.395 | 7.872 | 8.82 |
| 114.3 | – | – | – | – | – | – | 4.453 | 5.547 | 7.173 | 8.247 | 8.78 | 9.84 |
| 127 | – | – | – | – | – | – | 4.955 | 6.175 | 7.989 | 9.188 | 9.785 | 10.98 |
| 152.4 | – | – | – | – | – | – | 5.96 | 7.429 | 9.62 | 11.07 | 11.792 | 13.231 |
| Price List | Price in US |
| TP310H Seamless Stainless Steel | US $2200-4000 / Ton (FOB Price) |
| Seamless Pipes ASTM A312 TP310H | US $500-1100 / Ton (FOB Price) |
| Stainless Seamless Pipes TP310H | US $400-2000 / Ton (FOB Price) |
| ASTM A312 TP310H Stainless Steel Welded | US $840-2000 / Metric Ton (FOB Price) |
| SA312 TP310H Seamless Pipes | US $1.5-9 / Kilogram (FOB Price) |
| TP310H Seamless Manufacturer | US $840-2000 / Metric Ton (FOB Price) |
| ASTM A312 Gr. TP310H Welded | US $400-1000 / Ton (FOB Price) |
