We are Metinox Overseas, the manufacturer of the most popular Monel flanges in India, providing high-end piping parts for the critical industries. We are based in 2003 and have a long history of manufacturing excellence, which is backed by the ISO 9001:2008 certification. Our Monel flanges are made with high grade Monel alloys like Monel 400 and Monel K500, other nickel alloys, and corrosion-resistant alloys with strict compliance to international standards of quality.
We produce different Monel flanges, which come in different standards such as ANSI B16.5, ASME B16.47, MSS-SP44, API, AWWA-C207, and BS in our sophisticated production plants in Mumbai. Our range of products is Slip-On Monel Flanges, Weld Neck Monel Flanges, Blind Monel Flanges, Threaded Monel Flanges, Socket Weld Monel Flanges, Lap Joint Monel Flanges, all with classes of 150 Lbs up to 2500 LBS, such that they can be used with low-pressure systems and also high-pressure systems.
All the Monel flanges produced at Metinox Overseas are produced with a high degree of quality control and using premium-grade raw materials, high level of technology, and tight control of dimensions. We have large ready stocks in standard sizes, grades, and specifications; this allows us to deliver quickly in the Indian market and all over the world. Our Monel flanges find applications in the oil and gas, petrochemical processing, power generation, chemical plants, pharmaceuticals, marine and offshore platforms, water treatment, and thermal system industries through our focus on quality, technical reliability, competitive pricing, and punctual delivery.
Table of Contents
- Monel Flanges Specification
- Monel Flanges - Chemical Composition
- Mechanical Properties of Monel Alloy Flanges
- Monel flanges Equivalent Material Grades
- Dimensions of Monel Alloy Flanges
- Weight Chart of Monel Flanges
- Pressure rating of the Monel Flanges
- Types of Monel Flanges
- Application Usage of the Monel Flanges
- Monel Flanges Suppliers in India
- Monel Flanges Exporters in India
Monel Flanges by Grade
Monel Flanges Specification
Monel Flanges specification are given below, and for more information, contact us.
| Feature | Specification Details |
| Material Specification | ASTM A564 / ASME SA564 |
| Dimensions | ANSI/ASME B16.5, B16.47 (Series A & B), B16.48, BS 4504, BS 10, EN 1092, DIN |
| Standards | ANSI, ASME, BS, DIN, EN Flanges |
| Size Range | -" NB to 12" NB |
| Pressure Class | 150#, 300#, 600#, 900#, 1500#, 2500# |
| Pressure Rating (Metric) | PN 6, PN 10, PN 16, PN 25, PN 40, PN 64 |
| Flange Face Type | Flat Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
| DIN Flanges | 2527, 2566, 2573, 2576, 2641-42, 2655-56, 2627-29, 2631-38, 2673 |
| JIS Flanges | JIS B2220 (5K, 10K, 16K, 20K) |
| BS Flanges | BS 4504 (PN 6 to PN 250), BS 10 (Table D, E, F, H) |
Monel Flanges - Chemical Composition
The chemical composition ensures the strength of the material, so here is the detailed chemical composition of Monel Flanges.
| Grade (UNS) | Ni | Cu | Fe | Mn | C | Si | S | Al | Ti |
| Monel 400 (N04400) | min. 63.0% | 28.0-34.0% | max. 2.5% | max. 2.0% | max. 0.3% | max. 0.5% | max. 0.024% | - | - |
| Monel K-500 (N05500) | min. 63.0% | 27.0-33.0% | max. 2.0% | max. 1.5% | max. 0.25% | max. 0.5% | max. 0.01% | 2.30-3.15% | 0.35-0.85% |
Mechanical Properties of Monel Alloy Flanges
The mechanical properties will tell you about the tensile strength and other properties of the material, and the Monel Flanges properties is listed below.
| Properties | Monel 400 | Monel K-500 |
| Tensile Strength | 550 MPa (80 ksi) min | 1100 MPa (160 ksi) min |
| Yield Strength (0.2% Offset) | 240 MPa (35 ksi) min | 790 MPa (115 ksi) min |
| Elongation | 35% min | 20% min |
| Hardness (Brinell) | 125-175 HB | 265-300 HB |
Monel flanges Equivalent Material Grades
Monel Flanges come in different international grades, and all the grades are listed below.
| Grade Name | Werkstoff Nr. | UNS | JIS (Japan) | AFNOR (France) | BS (UK) | GOST (Russia) | EN (Europe) |
| Monel 400 | 2.4360 | N04400 | NW 4400 | NU-30M | NA 13 | ????? 28-2,5-1,5 | NiCu30Fe |
| Monel K500 | 2.4375 | N05500 | - | - | - | - | - |
Dimensions of Monel Alloy Flanges
The dimensions of the Monel alloy flanges provide you with the accurate information that helps you to create and analyze the cost and delivery prices.
| Nominal Size | Pressure Class | Flange Diameter | Bolt Circle Diameter | Num. of Bolts | Bolt Size | Bolt Hole Dia. |
| 15mm (1/2?) | ANSI 150 / 300 / 600 | 89 / 95 / 95 | 60 / 67 / 67 | 4 | 13 | 16 |
| ANSI 900 / 1500 | 121 | 83 | 4 | 19 | 22 | |
| 20mm (3/4?) | ANSI 150 | 98 | 70 | 4 | 13 | 16 |
| ANSI 300 / 600 | 117 | 83 | 4 | 16 | 19 | |
| ANSI 900 / 1500 | 130 | 89 | 4 | 19 | 22 | |
| 25mm (1?) | ANSI 150 | 110 | 79 | 4 | 13 | 16 |
| ANSI 300 / 600 | 125 | 89 | 4 | 16 | 19 | |
| ANSI 900 / 1500 | 150* | 102 | 4 | 22 | 25 | |
| 40mm (1 1/2?) | ANSI 150 | 127 | 98 | 4 | 13 | 16 |
| ANSI 300 / 600 | 156 | 114 | 4 | 19 | 22 | |
| ANSI 900 / 1500 | 178 | 124 | 4 | 25 | 29 | |
| 50mm (2?) | ANSI 150 | 152 | 121 | 4 | 16 | 19 |
| ANSI 300 / 600 | 165 | 127 | 8 | 16 | 19 | |
| ANSI 900 / 1500 | 216 | 165 | 8 | 22 | 25 | |
| 80mm (3?) | ANSI 150 | 191 | 152 | 4 | 16 | 19 |
| ANSI 300 / 600 | 210 | 168 | 8 | 19 | 22 | |
| ANSI 1500 | 267 | 203 | 8 | 29 | 32 | |
| 100mm (4?) | ANSI 150 | 229 | 191 | 8 | 16 | 19 |
| ANSI 600 | 273 | 216 | 8 | 22 | 25 | |
| ANSI 1500 | 311 | 241 | 8 | 32 | 35 | |
| 150mm (6?) | ANSI 150 | 279 | 241 | 8 | 19 | 22 |
| ANSI 300 | 318 | 270 | 12 | 19 | 22 | |
| ANSI 1500 | 394 | 318 | 12 | 35 | 38 | |
| 250mm (10?) | ANSI 150 | 406 | 362 | 12 | 22 | 25 |
| ANSI 600 | 508 | 432 | 16 | 32 | 35 | |
| ANSI 1500 | 584 | 483 | 12 | 41 | 51 | |
| 300mm (12?) | ANSI 150 | 483 | 432 | 12 | 22 | 25 |
| ANSI 600 | 559 | 489 | 20 | 32 | 35 | |
| ANSI 1500 | 673 | 571 | 16 | 51 | 54 | |
| 450mm (18?) | ANSI 150 | 635 | 578 | 16 | 29 | 32 |
| ANSI 600 | 743 | 654 | 20 | 41 | 44 | |
| ANSI 1500 | 914 | 775 | 16 | 70 | 73 | |
| 600mm (24?) | ANSI 150 | 813 | 749 | 20 | 32 | 35 |
| ANSI 600 | 940 | 838 | 24 | 48 | 51 | |
| ANSI 1500 | 1168 | 991 | 16 | 89 | 92 |
Weight Chart of Monel Flanges
The table below provides detailed information on the weight chart of the flanges.
| Pipe Size (inch) | DN | O.D. (O) | Thk (C) | Hub Dia (X) | RF Dia (G) | Length (Y) | BCD (BC) | Hole Dia | No. Bolts | Bolt Size | Weight (KG) |
| 1/2? | 15 | 89.0 | 11.2 | 30.2 | 35.1 | 15.7 | 60.5 | 15.8 | 4 | 1/2? | 0.4 |
| 3/4? | 20 | 98.5 | 12.7 | 38.1 | 42.9 | 15.7 | 69.9 | 15.8 | 4 | 1/2? | 0.7 |
| 1? | 25 | 108.0 | 14.2 | 49.3 | 50.8 | 17.5 | 79.3 | 15.8 | 4 | 1/2? | 0.8 |
| 1-1/4? | 32 | 117.5 | 15.7 | 58.7 | 63.5 | 20.6 | 88.9 | 15.8 | 4 | 1/2? | 1.2 |
| 1-1/2? | 40 | 127.0 | 17.5 | 65.0 | 73.2 | 22.4 | 98.6 | 15.8 | 4 | 1/2? | 1.5 |
| 2? | 50 | 152.5 | 19.1 | 77.7 | 91.9 | 25.4 | 120.7 | 19.1 | 4 | 5/8? | 2.3 |
| 2-1/2? | 65 | 178.0 | 22.4 | 90.4 | 104.6 | 28.4 | 139.7 | 19.1 | 4 | 5/8? | 3.7 |
| 3? | 80 | 190.5 | 23.9 | 108.0 | 127.0 | 30.2 | 152.4 | 19.1 | 4 | 5/8? | 4.1 |
| 3-1/2? | 90 | 216.0 | 23.9 | 122.2 | 139.7 | 31.8 | 177.8 | 19.1 | 8 | 5/8? | 5.1 |
| 4? | 100 | 228.5 | 23.9 | 134.9 | 157.2 | 33.3 | 190.5 | 19.1 | 8 | 5/8? | 5.9 |
| 5? | 125 | 254.0 | 23.9 | 163.6 | 185.7 | 36.6 | 215.9 | 22.4 | 8 | 3/4? | 7.0 |
| 6? | 150 | 279.5 | 25.4 | 192.0 | 215.9 | 39.6 | 241.3 | 22.4 | 8 | 3/4? | 8.4 |
| 8? | 200 | 343.0 | 28.4 | 246.1 | 269.7 | 44.5 | 298.5 | 22.4 | 8 | 3/4? | 13.0 |
| 10? | 250 | 406.5 | 30.2 | 304.8 | 323.9 | 49.3 | 362.0 | 25.4 | 12 | 7/8? | 18.0 |
| 12? | 300 | 482.5 | 31.8 | 365.3 | 381.0 | 55.6 | 431.8 | 25.4 | 12 | 7/8? | 29.0 |
| 14? | 350 | 533.5 | 35.1 | 400.1 | 412.8 | 57.2 | 476.3 | 28.5 | 12 | 1? | 39.0 |
| 16? | 400 | 597.0 | 36.6 | 457.2 | 469.9 | 63.5 | 539.8 | 28.5 | 16 | 1? | 47.0 |
| 18? | 450 | 635.0 | 39.6 | 505.0 | 533.4 | 68.3 | 577.9 | 31.8 | 16 | 1-1/8? | 57.0 |
| 20? | 500 | 698.5 | 42.9 | 558.8 | 584.2 | 73.2 | 635.0 | 31.8 | 20 | 1-1/8? | 76.0 |
| 24? | 600 | 813.0 | 47.8 | 663.4 | 692.2 | 82.6 | 749.3 | 35.1 | 20 | 1-1/4? | 97.0 |
Pressure rating of the Monel Flanges
The pressure rating will help to select the suitable Monel flanges according to your requirements. So the table provides the detailed information on the monel flanges.
| Temperature (-F) | 150# | 300# | 400# | 600# | 900# | 1500# | 2500# |
| -20 to 100 | 275 | 720 | 960 | 1440 | 2160 | 3600 | 6000 |
| 200 | 230 | 600 | 800 | 1200 | 1800 | 3000 | 5000 |
| 300 | 205 | 540 | 720 | 1080 | 1620 | 2700 | 4500 |
| 400 | 190 | 495 | 660 | 995 | 1490 | 2485 | 4140 |
| 500 | 170 | 465 | 620 | 930 | 1395 | 2330 | 3880 |
| 600 | 140 | 435 | 580 | 875 | 1310 | 2185 | 3640 |
| 700 | 110 | 425 | 565 | 850 | 1275 | 2125 | 3540 |
| 800 | 80 | 405 | 540 | 805 | 1210 | 2015 | 3360 |
| 900 | 50 | 390 | 520 | 780 | 1165 | 1945 | 3240 |
| 1000 | 20 | 320 | 430 | 640 | 965 | 1605 | 2675 |
| 1100 | 20 | 255 | 345 | 515 | 770 | 1285 | 2145 |
| 1200 | 20 | 155 | 205 | 310 | 465 | 770 | 1285 |
| 1300 | 20 | 85 | 115 | 170 | 255 | 430 | 715 |
| 1400 | 20 | 50 | 65 | 95 | 145 | 240 | 400 |
| 1500 | 10 | 25 | 35 | 55 | 80 | 135 | 230 |
Types of Monel Flanges
Metinox Overseas would like to provide a full product line of Monel flanges that are designed with high quality and are designed to work well in a challenging piping system. All flanges are precision-forged and come in various pressure classes, such as Class 150 through to Class 2500, making them meet the international standard and are applicable to various industrial uses.
Weld Neck Flange (WNRF)
This is a high-pressure and high-temperature designed flange with a long tapered hub and butt-welded joint to minimize stress concentration and provide a strong and leak-free connection.
Slip-On Flange (SORF)
A cost-effective and simple-to-install type of low to medium-pressure system. It is fast to align, and minimal welding is necessary to install the device and it is easy and efficient.
Blind Flange (BLRF)
It is used to close the end of a pipeline or valve opening and it offers a safe closure and the possibility to expand the system in the future or to have access to maintenance.
Socket Weld Flange (SWRF)
This is a small-diameter, high-pressure piping flange that is ideal and offers good fatigue strength, a smooth internal bore, and a good and strong joint.
Threaded Flange (THRF)
This flange is designed to be connected directly to the pipe, allowing a quick and safe connection, and a heat-free connection since welding is not an option or allowed.
Lap Joint Flange (LJRF)
Applied to stub ends, this flange fits well in systems that need frequent dismantling. It is rotating in design and can be readily aligned by bolting it, and also, maintenance and inspection is simplified.
Orifice Flange
The flange is specially designed to be used in flow measurement applications and has orifice plates that have jack screws and bolt assemblies to accurately measure the flow of liquids and gases.
Application Usage of the Monel Flanges
Monel flanges are designed to be used in harsh conditions where strength, resistance to corrosion and reliability are the most important factors. They work in chemical, marine, and high temperature environment and can thus be used in most industrial applications.
Chemical and Petrochemical industries
Applied in the manipulation of corrosive chemicals, acids, alkalis, and high-pressure process fluids with long life.
Pharmaceutical Manufacturing
Applicable in high-purity systems where stability on material, cleanliness and contaminability properties are a must.
Power Generation
Used in thermal plants and nuclear plants as steam lines, heat exchangers and high temperature systems where oxidation and pressure resistance are needed.
Engineering & Heavy Industry
Embedded in heavy machinery, industrial plants and in the vital piping systems where structural integrity and dependability are critical.
Marine and Offshore
Ideal in seawater systems, offshore platforms and shipbuilding as it has great resistance to salt water corrosion, chloride attack and erosion.
