Stainless Steel Pipe Weight Calculator & Chart

Stainless Steel Pipe Weight Calculator & Chart helps you determine steel pipes weight. It calculates the weight per meter and compares the weight of the ss pipe with the standard metric weight. Once you know the weight of the pipe, you can choose a suitable material. The weight per meter is an essential factor in deciding the cost of the pipe. Apart from that, you can use the weight per meter to determine the cost of metal structures.

Check out Free Online Stainless Steel Pipe Weight Calculator & Chart

Following Steel Pipe Weight Calculator is helpful in determining the weight of a steel pipe based on the material density, size, and grade. It also gives you an idea of the steel quality.

Steel Pipe Weight Calculator, SS Pipe Weight Calculator, SS 304 Pipe Weight Calculator, SS Square Pipe Weight Calculator, SS Round Pipe Weight Calculator

 O.D (mm) - W. Thick (mm) x L. Thick (mm) x Calculation

Stainless Steel Pipe Weight Chart, SS Pipe Weight Chart, SS 304 Pipe Weight Chart, SS 316 Pipe Weight Chart

Below Stainless Steel Pipe Weight Chart will tell you how much an individual meter weighs, and what pressure the steel pipe will withstand. Whether you are looking to install ss pipes for a plumbing fixture, business or are just looking for some information about the steel pipe's weight, refer the following stainless steel pipe weight chart to get some full insights.

 Nominal Pipe Size Outside Diameter Schedule 5 S Schedule 10 S Schedule 40 S Schedule 80 S Schedule 160 S XXS mm inch mm WT mm WEIGHT (KGM) WT mm WEIGHT (KGM) WT mm WEIGHT (KGM) WT mm WEIGHT (KGM) WT mm WEIGHT (KGM) WT mm WEIGHT (KGM) 3 1/8 10.3 1.2 0.20 1.24 0.28 1.73 0.37 2.41 0.47 – – – – 6 1/4 13.7 1.2 0.37 1.65 0.49 2.24 0.630 3.02 0.80 – – – – 10 3/8 17.1 1.2 0.47 1.65 0.63 2.31 0.840 3.20 1.10 – – – – 15 1/2 21.3 1.65 0.80 2.11 1.00 2.77 1.27 3.73 1.62 4.75 1.94 7.47 2.55 20 3/4 26.7 1.65 1.03 2.11 1.28 2.87 1.69 3.91 2.20 5.56 2.90 7.82 3.64 25 1 33.4 1.65 1.30 2.77 2.09 3.38 2.50 4.55 3.24 6.35 4.24 9.09 5.45 32 1.1/4 42.2 1.65 1.65 2.77 2.70 3.56 3.39 4.85 4.47 6.35 5.61 9.70 7.77 40 1.1/2 48.3 1.65 1.91 2.77 3.11 3.68 4.05 5.08 5.41 7.14 7.25 11.1 10.18 50 2 60.3 1.65 2.40 2.77 3.93 3.91 5.44 5.54 7.48 8.74 11.11 11.07 13.44 65 2.1/2 73.0 2.11 3.69 3.05 5.26 5.16 8.63 7.01 11.41 9.53 14.91 14.02 20.39 80 3 88.9 2.11 4.51 3.05 6.45 5.49 11.29 7.62 15.27 11.1 21.30 15.24 27.68 100 4 114.3 2.11 5.84 3.05 8.36 6.02 16.07 8.56 22.32 13.49 33.54 17.12 41.03 125 5 141.3 2.77 9.47 3.40 11.57 6.55 21.8 9.53 30.97 15.88 49.11 19.05 57.43 150 6 168.3 2.77 11.32 3.40 13.84 7.11 28.26 10.97 42.56 18.25 67.53 21.95 79.22 200 8 219.1 2.77 14.79 3.76 19.96 8.18 42.55 12.7 64.64 23.01 111.27 22.23 107.92 250 10 273.1 3.40 22.63 4.19 27.78 9.27 60.31 12.7 96.01 28.58 172.33 25.40 155.15 300 12 323.8 3.96 31.25 4.57 36.00 9.53 73.88 12.7 132.05 33.32 238.76 25.40 186.97 350 14 355.6 3.96 34.36 4.78 41.3 11.13 94.59 19.05 158.08 35.71 281.70 - - 400 16 406.4 4.19 41.56 4.78 47.29 12.7 123.30 21.41 203.33 40.46 365.11 - - 450 18 457.2 4.19 46.81 4.78 53.26 14.27 155.80 23.8 254.36 45.71 466.40 - - 500 20 508.0 4.78 59.25 5.54 68.61 15.09 183.42 26.19 311.2 49.99 564.68 - - 600 24 609.6 5.54 82.47 6.35 94.45 17.48 255.41 30.96 442.08 59.54 808.22 - -

How To Calculate Weight Of Stainless Steel Pipe?

A vital characteristic of any pipe is calculating the weight of it. The Stainless Steel Pipe Weight Calculator calculates the steel pipe's weight by evaluating its grade and density. The formula then calculates the amount of steel required to make the pipe.

First, determine stainless steel pipes' outside and inside diameters to calculate their weight. These measurements will allow you to calculate the pipe's weight using the following formulas.
Wt/Ft = 10.69*(OD - Wall Thickness)*Wall Thickness.
Next, multiply the alloy density using the formula below. The formula can calculate the pipe's mass once you have determined the outside and inside diameters. The pipe's surface area can be used to calculate its weight.

You can calculate the weight of stainless steel pipes using this formula:
Weight (Kg)= ∏/4*(OD2-ID2)*L*p.
The metric system is widely used in manufacturing and has been an essential tool for industrial companies. Stainless steel pipes are used in many applications, such as the construction of tanks, valves, and pipes. There are many sizes and grades of stainless steel pipe. A weight calculator will help you find a suitable stainless steel pipe for your project. You can try our online ss pipe calculator to calculate the weight.

The pipe's internal and exterior diameters will determine its weight. You can also control the wall's thickness. You can also control the steel type to affect its strength or flexibility. To ensure the correct weight of your stainless steel pipe, you can adjust the length, coating material, end finish, and other parameters. Make sure you include all dimensions when you calculate the weight.

Once you've calculated the weight of the stainless steel pipe, you need to consider the size. You will need to measure the length of the pipe you require, as some sizes are smaller than others. A smaller pipe will have fewer threaded connections than a larger-diameter one. Before you buy stainless steel pipes for construction, weigh all the options before you make any final decisions. A SS pipe weight calculator can help you determine the cost of a pipe.

The size and thicknesses of stainless steel pipes are essential factors in determining the pipe's weight. A welded pipe may weigh three times more than a small one. You can calculate the mass of stainless steel pipes to determine their weight and order the right amount.
